STS-130

USA

Manned Flight nº: 273

Earth orbit Flight nº: 270

USA manned Flight nº: 161

53th manned flight to ISS. Flight: ISS-20A

Launch, orbit & landing data:

Designation	36394 / 10004A
Launch date - time	08 Feb 2010 - 09:14 UT
Launch site	KSC, LC39A
Launch vehicle	Space Shuttle
Orbiter	Endeavour #24
Primary payload	Node 3 (Tranquility) & Cupola
Mass (kg)	99863 kg
Earth orbit on Feb 8.42:
- Perigee / Apogee	200 x 231 km
- Eccentricity	0.002
- Inclination	51.63°
- Period	88.82 min
Docking date - time	10 Feb 2010 - 05:06 UT
Target spacecraft/port	ISS/PMA-2/Harmony port
Docking orbit on Feb 11.56:
- Perigee / Apogee	334 x 349 km
- Eccentricity	0.001
- Inclination	51.64°
- Period	91.37 min
Undocking date - time	20 Feb 2010 - 00:54 UT
Landing date - time	22 Feb 2010 - 03:20 UT
Landing location	KSC runway 15
Flight Duration (d:hr:min)	13d 18h 06m (13.75 days)
Nbr orbits	217
Landing crew	idem launch crew

Note: Mass quoted is at orbit insertion, excluding mass of Tranquillity & Cupola.

Crew

Nr.	Name	Job	Duration
1	Zamka, George David	CDR	13d 18h 06m
2	Virts, Terry Wayne	PLT	13d 18h 06m
3	Hire, Kathryn Patricia	MSP	13d 18h 06m
4	Robinson, Stephen Kern	MSP	13d 18h 06m
5	Behnken, Robert Louis	MSP	13d 18h 06m
6	Patrick, Nicholas James	MSP	13d 18h 06m

Payload path

Mission details:

Launch from Cape Canaveral (KSC); landing at Cape Canaveral (KSC); ISS-20A Tranquility (formerly: NODE 3), Cupola.

STS-130 cargo manifest
  ----------------------

  Name                             Bay location   Mass (kg,guess)

  Orbiter Docking System           1-2            1800
   with EMU 3004, 3005 suits                       260?
  APC/SPDU                         3 port           18
  APC/SPDU                         7 port           17
  Tranquility Node                 8-12          13004
  Cupola                           7              1805
  RMS 201                          Sill            410
  OBSS                             Sill            382
  -----------------------------------------------------
                                           Total 17696 kg SDO

At 09:22 UT, Endeavour entered a 58 x 229 km x 51.6 deg orbit. Then at 09:51 the OMS engines ignited for a 1min33s, 43.3m/s burn to raise perigee out of the atmosphere. By 20:10 UTC, after a further burn, Endeavour was in a 206 x 233 km x 51.7 deg orbit.
Following a two day solo flight Endeavour docked with the Station in a 301 x 348 km orbit at 05:06 UTC on Feb 10. After a somewhat longer than normal waiting period for oscillations to damp down, the docking ring was retracted for a firm seal at 05:55 UTC. Joint operations with the ISS expedition 22.

STS-130 in orbit

Arrives at the ISS

ISS crew after docking
First EVA by Behnken and Patrick on 12.02.2010 (6h 32m)
The airlock hatch was opened at 02:16 UTC; Node 3 was unberthed from the Shuttle at 04:05 UTC and attached to the Unity module between 05:56 and 06:20 UTC.
Behnken used spacesuit 3018, replacing the planned suit 3004 which had a power harness problem. Patrick used suit 3005; it developed a fan problem during the spacewalk so suit 3004 will be repaired and used by him during the forthcoming second and third spacewalks.
They remove a cover that has been in place to protect a port on the Unity node, the location where Tranquility was attached robotically halfway through the spacewalk. Next, the spacewalkers removed and stored a spare parts platform from the Special Purpose Dexterous Manipulator, or DEXTRE, a two-armed space station robot capable of handling delicate assembly tasks currently performed by spacewalkers. Finally, they installed four electronics systems cables between Unity and Tranquility to bring the new node to life.

EVA Patrick

EVA Behnken
From inside the station, Virts and Hire used the station's robotic arm to remove Tranquility from the shuttle's payload bay, then carefully maneuver then installed the node onto the port side of the Unity node. Tranquility was built for NASA by Thales Alenia Space in Turin, Italy, under contract to the European Space Agency.
Second EVA by Behnken and Patrick on Feb 14, 2010 (5h 54m), with Quest airlock depressurization at 02:19 UTC and hatch open at 02:20 UTC. Patrick, in SEMU 3004, and Behnken, in SEMU 3018; they install ammonia plumbing connectors between Unity and Tranquility and covering them with thermal insulation. When turned on, the ammonia will provide cooling to Tranquility. Then they prepared a port on the Earth-facing side of Tranquility for the flight day 8 relocation and attachment of the Cupola. The spacewalk ended with repressurization of Quest at 08:14 UTC.

Tranqulity

2e EVA Patrick
The Cupola was unberthed from the end of the Tranquility module at 05:24 UTC Feb 15, after an hour's delay due to uncooperative bolts and latches. The Cupola is 4.9 feet in length, 9.7 feet in diameter and has a weight of about 4,145 pounds in orbit. The Cupola includes window shutters that provide orbital debris protection when closed.

Cupola relocation

PMA3 relocation
PMA-3 was unbolted from the zenith location on the Harmony module at 00:52 UTC on Feb 16 and moved by the SSRMS arm to the end location on Tranquility, where the Cupola used to be. PMA-3 was fixed in its new location at 0228 UTC.
Third and final EVA by Behnken and Patrick on 17.02.2010 (5h 48m); Behnken used SEMU 3005 and Patrick used SEMU 3004. Quest was depressurized at 0213 UTC, with hatch open a minute later.
They turn on the ammonia cooling lines between Unity and Tranquility, installing heater and data cables on Tranquility, removing insulation and launching locks from the newly-installed Cupola, and installed handrails on the outside of Tranquility.
The airlock was repressurized at 0803 UTC, with Cupola′s newly open window shutters exposing the windows and giving the crew a new view of the Earth.

Inter. Cupola

ISS at the end of STS-130
Endeavour undocked at 00:54 UTC on Feb 20. The OMS engines were fired at 02:14 UTC on Feb 22 to drop the vehicle out of orbit, and it landed on runway 15 at Kennedy Space Center at 03:20 UTC.

Landing
