STS-44

USA


Manned Flight nº: 146

Earth orbit Flight nº: 143

USA manned Flight nº: 75


Launch, orbit & landing data:

Designation 21795 / 91080A
Launch date - time 24 Nov 1991 - 23:44:00 UT
Launch site KSC, LC39A
Launch vehicle  Space Shuttle
Orbiter Atlantis OV-104 (#10)
Primary payload DSP-F16
Mass (kg)
Flight Crew Gregory, Henricks, Voss
Musgrave, Runco, Hennen
Call Sign
Earth orbit on :
   - Perigee / Apogee  km
   - Inclination 28.5°
   - Period  min
Landing date - time 01 Dec 1991 - 22:34:42 UT
Landing location Edwards AFB, Runway 05
Flight Duration (d:hr:min) 6d 22h 50m
Nbr orbits 110

Crew

Nr. Surname Given name Job Duration
1  Gregory  Frederick Drew  CDR 6d 22h 50m
2  Henricks  Terence Thomas  PLT 6d 22h 50m
3  Musgrave  Franklin Story  MSP 6d 22h 50m
4  Runco  Mario, Jr.  MSP 6d 22h 50m
5  Voss  James Shelton  MSP 6d 22h 50m
6  Hennen  Thomas John  MSE 6d 22h 50m

Mission details:

Launch from Cape Canaveral (KSC); landing on Edwards AFB; dedicated Department of Defense mission; deploying of DSP-16-satellite; COLA-maneuver to fly in save distance to Kosmos 851-launch rocket; premature return to Earth due of to technical problems.

DSP F16 launched by STS-44




25 November 1991 23:45 GMT. Duration: 6.95 days. Payload: Atlantis F10 / DSP 16 [IUS]. Mass: 20,242 kg. Perigee: 363 km. Apogee: 371 km. Inclination: 28.5 deg. Period: 91.9 min.

Manned six crew. Deployed Defense Support Program satellite. Payloads: Defense Support Program satellite/ Inertial Upper Stage, Interim Operational Contamination Monitor, Terra Scout, Military Man in Space, Shuttle Activation Monitor, Cosmic Radiation Effects and Activation Monitor, Radiation Monitoring Equipment Ill, Air Force Maui Optical Site Calibration Test, Ultraviolet Plume Instrument, Visual Function Tester 1.

Orbits of Earth: 109. Distance traveled: 4,651,111 km. Orbiter Liftoff Mass: 117,765 kg. Orbiter Mass at Landing: 87,915 kg. Payload to Orbit: 20,242 kg. Payload Returned: 3,179 kg. Landed at: Runway 05 dry lake bed at Edwards Air Force Base, . Landing Speed: 339 kph. Touchdown miss distance: 794 m. Landing Rollout: 3,411 m.



NASA Official Mission Narrative

Mission Name: STS-44 (44)
Atlantis (10)
Pad 39-A (43)
44th Shuttle mission
10th flight OV-104
Shortened mission
Diverted landing

Crew:
Frederick D. Gregory (3), Commander
Terence T. Henricks (1), Pilot
F. Story Musgrave (4), Mission Specialist
Mario Runco, Jr. (1), Mission Specialist
James S. Voss (1), Mission Specialist
Thomas J. Hennen (1), Payload Specialist

Milestones:
OPF - Aug. 12,1991
VAB - Oct. 18, 1991
PAD - Oct. 23,1991

Payload:
DSP,IOCM,MODE(2),AMOS(2),MMIS,CREAM,SAM,RME-III,VFT-1,UVPI,BFPT,EDOMP
Mission Objectives:

Launch:
November 24, 1991, 6:44:00 p.m. EST. Launch set for Nov. 19 delayed due to malfunctioning redundant inertial measurement unit on inertial Upper Stage booster attached to Defense Support Program satellite. Unit replaced and tested. Launch reset for Nov. 24, delayed 13 minutes to allow an orbiting spacecraft to pass and to allow external tank liquid oxygen replenishment after minor repairs to valve in the liquid oxygen replenishment system in the mobile launcher platform. Launch Weight: 259,629 lbs.
Orbit:
Altitude: 197nm
Inclination: 28.5 degrees
Orbits: 110
Duration: 6 days, 22 hours, 50 minutes, 44 seconds.
Distance: 2,890,067 miles

Hardware:
SRB: BI-047
SRM: 360L/W019
ET : 53/LWT-46
MLP : 1
SSME-1: SN-2015
SSME-2: SN-2030
SSME-3: SN-2029

Landing:
December 1, 1991, 2:34:12 p.m. PST, Runway 5. Edwards Air Force Base, Calif. Rollout distance: 11,191 feet. Rollout time: 107 seconds. Landing originally scheduled for KSC on Dec. 4, but ten-day mission shortened and landing rescheduled following Nov. 30 on-orbit failure of one of three orbiter inertial measurement units. Lengthy rollout due to minimal braking for test. Orbiter returned to KSC on Dec. 8. Landing Weight: 193,825 lbs.

Mission Highlights:
Dedicated Department of Defense mission. Unclassified payload included Defense Support Program (DSP) satellite and attached Inertial Upper Stage (IUS), deployed on flight day one. Cargo bay and middeck payloads: Interim Operational Contamination Monitor(IOCM); Terra Scout; Military Man in Space (M88-1); Air Force Maui Optical System (AMOS); Cosmic Radiation Effects and Activation Monitor (CREAM); Shuttle Activation Monitor (SAM); Radiation Monitoring Equipment III (RME III); Visual Function Tester-1 (VFT-1); Ultraviolet Plume Instrument (UVPI). Bioreactor Flow and Particle Trajectory experiment; and Extended Duration Orbiter Medical Project, a series of investigations in support of Extended Duration Orbiter.
