Galaxy-4R |
USA |
| Designation | 26298 / 00020A |
| Launch date | 19 Apr 2000 - 00:29 UT |
| Launch site | Ko, ELA-2 |
| Launch vehicle | Ariane-42L (V-129) |
| Mission | Commercial: Communications |
| Geostationary orbit on April 27.59, 2000: | |
| Perigee / Apogee | 35760 x 35792 km |
| Eccentricity | 0.0003 |
| Inclination | 0.04 deg |
| Period | 1435.58 min |
| Prime contractor | Boeing Satellite Systems (Hughes?) |
| Operator | PanAmSat (Intelsat, Ltd.) |
| Platform | HS-601HP |
| Mass at launch | 3668 kg |
| Dry mass | 1895 kg |
| Mass in orbit | 2511 (3668?) kg |
| Basic shape | Box + 2 panels |
| Dimension | stowed: 2.7 x 3.6 x 4 m |
| Solar array | 26 m span, gallium arsenide |
| Stabilization | 3-axis |
| DC power |
BOL:
8800 W EOL: 7800 W |
| Design lifetime | 15 years |
| Date | Position | Remarks |
| L: 19 Apr 2000 | 73°W | - |
| Jun 2000 | 99°W | - |
| Apr 2009 | 76.89°W | - |
| Main transponders | 24 |
| Backup transponders | 4 |
| Power | 40 W |
| Bandwidth | 36 MHz |
| Coverage | North America |
| EIRP max | 41 dBW |
| G/T max | -1 dB/K |
| Polarization | linear H/V |
| SFD | -94 dBW/m² (at 0 G/T & 0 dB attenuation) |
| Frequencies |
Uplink:
5.925 - 6.425 GHz Downlink: 3.700 - 4.200 GHz |
| Main transponders | 24 |
| Backup transponders | 4 |
| Power | 108 W |
| Bandwidth | 36 MHz |
| Coverage | North America |
| EIRP max | 45 dBW |
| G/T max | 0 dB/K |
| Polarization | linear H/V |
| SFD | -94 dBW/m² (at 0 G/T & 0 dB attenuation) |
| Frequencies |
Uplink:
14.000 - 14.500 GHz Downlink: 11.700 - 12.200 GHz |
|
Horizontal Uplink |
Horizontal Downlink | Transponder |
Vertical Downlink |
Vertical Uplink |
| 11.720 | 1 | 14.020 | ||
| 14.040 | 2 | 11.740 | ||
| 11.760 | 3 | 14.060 | ||
| 14.080 | 4 | 11.780 | ||
| 11.800 | 5 | 14.100 | ||
| 14.120 | 6 | 11.820 | ||
| 11.840 | 7 | 14.140 | ||
| 14.160 | 8 | 11.860 | ||
| 11.880 | 9 | 14.180 | ||
| 14.200 | 10 | 11.900 | ||
| 11.920 | 11 | 14.220 | ||
| 14.240 | 12 | 11.940 | ||
| 11.960 | 13 | 14.260 | ||
| 14.280 | 14 | 11.980 | ||
| 12.000 | 15 | 14.300 | ||
| 14.320 | 16 | 12.020 | ||
| 12.040 | 17 | 14.340 | ||
| 14.360 | 18 | 12.060 | ||
| 12.080 | 19 | 14.380 | ||
| 14.400 | 20 | 12.100 | ||
| 12.120 | 21 | 14.420 | ||
| 14.440 | 22 | 12.140 | ||
| 12.160 | 23 | 14.460 | ||
| 14.480 | 24 | 12.180 |
|
