Galaxy 10R

USA

Launch data:

Designation:	26056 / 00002A
Launch date	25 Jan 2000 - 01:04 UT
Launch site	Ko, ELA-2
Launch vehicle	Ariane-42L (V-126)
Mission	Telecommunications
Geostationary orbit	123°W
Geostationary orbit on 2000 Feb 1.02:
Perigee / Apogee	34231 x 35783 km
Eccentricity	0.019
Inclination	0.19°
Period	1396.48 min

Tested at 127°W during Feb 2000

Specifications

Prime contractor	Hughes
Platform	HS-601HP
Mass at launch	3651 kg
Mass in orbit	2137 kg
Dry mass	1987 kg
Basic shape	Box + 2 panels
Dimension	6.0 x 3.4 x 2.28 m
Solar array	26.2m span, dual-junction gallium arsenide
Stabilization	3-axis
DC power	BOL: 8800 W EOL: 7800 W
Design lifetime	> million years

Location:

Begin	End	Position

09 Jun 2008		drifting to the West

First use of the LAE of Kaiser Marquardt of Van Nuys, CA USA; it is aimed to boost the satellite in GEO from GTO. It consumes monomethyl hydrazine and nitrogen tetroxide. Because it uses advanced materials, the new, high-performance engine operates about 700 degrees Fahrenheit hotter than conventional satellite engines, resulting in greater propellant efficiency and higher performance. It provides a specific impulse of approximately 322 seconds as compared to the 315 seconds provided by standard apogee motors.

XIPS propulsion.

Beacons: 4.198125 V and 4.199625 H GHz
ULPC: 12.195 V and 11.701 H GHz

C-band

Main transponders	24
Backup transponders	4
Power	40 W
Bandwidth	36 MHz
Coverage	North America
EIRP max	41.5 dBW
G/T max	-1 dB/K
Polarization	linear H/V
SFD	-94 dBW/m² (at 0 G/T & 0 dB attenuation)
Frequencies	Uplink: 5.925 - 6.425 GHz Downlink: 3.700 - 4.200 GHz

Ku-band

Main transponders	24
Backup transponders	4
Power	108 W
Bandwidth	36 MHz
Coverage	North America
EIRP max	47.5 dBW
G/T max	0 dB/K
Polarization	linear H/V
SFD	-95 dBW/m² (at 0 G/T & 0 dB attenuation)
Frequencies	Uplink: 14.000 - 14.500 GHz Downlink: 11.700 - 12.200 GHz

Ku-band transponder frequency chart (GHz)

Horizontal Uplink	Horizontal Downlink	Transponder	Vertical Downlink	Vertical Uplink
14.020		1	11.720
	11.740	2		14.040
14.060		3	11.760
	11.780	4		14.080
14.100		5	11.800
	11.820	6		14.120
14.140		7	11.840
	11.860	8		14.160
14.180		9	11.880
	11.900	10		14.200
14.220		11	11.920
	11.940	12		14.240
14.260		13	11.960
	11.980	14		14.280
14.300		15	12.000
	12.020	16		14.320
14.340		17	12.040
	12.060	18		14.360
14.380		19	12.080
	12.100	20		14.400
14.420		21	12.120
	12.140	22		14.440
14.460		23	12.160
	12.180	24		14.480

Mission details:

Galaxy 10R, is a replacement for Galaxy 10, lost on the first Delta 3 launch failure. It carries Ku and C band transponders and will be parked at 127 deg W.
The Ariane 4, flight V126, had two strap-on liquid boosters. The three stage vehicle flew from the ELA 2 pad on the coast of French Guiana directly to a 217 x 33232 km x 7.0 deg geostationary transfer orbit.

Astrophilately covers:

Launch cancel Kourou

Headquarter cancel Paris

Credit covers: J.VdDr.

Ref.: #7(JR419), #15, #206, #225(0806), #415 - update: 04.11.19
