Firewheel (Feuerrad)

Spacecraft Nº:

Germany spacecraft Nº:

Launch data: Designation  80F02 Launch date  23 May 1980 - 14:29:39 UT Launch site  Ko, ELA-1 Launch vehicle  Ariane-1 (L02) Mission  Research Decay  23 May 1980 Launch failure (Explosed).

Firewheel (with 4 Subsats on top)

Spacecraft data:

Description:

• The Firewheel spacecraft was designed to make barium and lithium ion releases in the night magnetosphere at 9.5 and 7 Re, respectively, and over North and South America. The main spacecraft was to carry 12 ejectable ion release containers. Diagnostic measurements were to be made on the main spacecraft and on four ejectable sub-payloads. These sub-payloads are total approximately 200 kg. Optical measurements were to be made from the ground and from aircraft.
• The scientific objectives were:
  • study of the plasma processes controlling the formation and decay of a magnetic cavity;
  • study of the momentum exchange with the ambient dilute plasma and of the long-range magnetoshperic perturbations generated thereby;
  • modification of the interaction of trapped energetic particles with self-generated whistler mode and ion cyclotron waves; and
  • tracing of acceleration and redistribution of the injected ions in the inner magnetosphere.
• The spacecraft would have been battery powered, with a lifetime of less than 48 hours.

Astrophilately covers:

Launch cancel Kourou. Credit: #411

Headquarter cancel Paris. Credit: #411
