Compass-G2 (BD-2 G2)

Beidou Daohang Weixing-2
Also called: Beidou 2 and BDW-2G.

Designation	34779 / 09018A
Launch date	14 Apr 2009 - 16:16 UT
Launch site	Xichang, LC1B
Launch vehicle	CZ-3C
Mission	Military: Navigation/Global Positioning
Geosynchronous orbit on Apr 29.99:
Perigee / Apogee	35775 x 35798 km
Eccentricity	2.02E-04
Inclination	0.95 deg
Period	1436.08 min

Prime contractor	China Academy of Space Technology (CASC)
Platform	DFH-3A bus
Operator	Chinese Defense Ministry
Mass at launch	2200 kg
Dry Mass	kg
Basic shape
Dimension (m)	2.2 x 1.72 x 2.0 m
Solar array	2 vanes of solar panels span 18.1 m
Stabilization
DC power
Design lifetime	~5 years

First Beidou Daohang Weixing-2 (Beidou navigation satellite) to be launched to geosynchronous orbit: the overall navigation satellite constellation is called "Compass".
On Apr 14, 2009 China launched the second "second generation" Beidou navigation satellite, COMPASS-G2 or 'Beidou Daohang Weixing' using the CZ-3C (Chang Zheng sanhao bing) launch vehicle. The satellite was initially placed in geostationary transfer orbit.
The first four Beidou were called ′Beidou Daohang Shiyan Weixing′, or Beidou Navigation Test Satellite; the most recent two are the operational 'Beidou Daohang Weixing'.

Compass-G2 launch cancel. Credit: #410

Ref.: #7(JR610), #14, #225(09.04), #226, #410 - update: 22.01.19
