CZ-8 _ CZ-8A

China (PR)


Description:


CZ-8A

  • Long March 8 is an orbital launch vehicle developed by the China Academy of Launch Vehicle Technology to launch up to 5000 kg to a 700 km altitude Sun-synchronous orbit (SSO).
  • The rocket is based on the Long March 7 with its dual engine first stage and single engine boosters, along with the existing liquid hydrogen burning third stage of the Long March 3A/3B/3C and 7A as its second stage.
  • Whereas the LM-7 uses 4 boosters, the LM-8 normally uses just 2. The boosters are omitted in the "core only" variant that first flew on its second launch in February 2022.
  • In 2018 it was planned that a future launch vehicle variant of the Long March 8 will be partially reusable by featuring a combined booster recovery of the first stage and the boosters as a single unit
  • The maiden flight of the Long March 8 was launched on 22 December 2020 from the Wenchang Spacecraft Launch Site.
    The "core only" variant first flew in February 2022

Technical Data:

Design Features -
Core Stages 2
Strap-on Boosters 4
Length 53.075 m
Diameter 3.35 m
Gross Mass 597 t
Lift-off Thrust 7200 kN
Payload Capacity 13.5 t (LEO) or 5.5 t (SSO)
First flight 25 June 2016
Launch centre Wenchang
Stage 1st Stage K3 Strap-on boosters K2 2nd Stage (CZ-8)
Length (m) 25.083 m 26.903 m 12.375 m
Diameter (m) 3.35 m 2.25 m 3 m
Engine 2x YF-100 1x YF-100 2x YF-75
Mass (Gross) (kg) N/A N/A N/A
Thrust (kN) 2400 kN (sea-level) 1200 kN (sea-level) 167 kN (vacuum)
Propellants RP-1 / LOX RP-1 / LOX LH2 / LOX

Stage Payload fairing
Length (m) 12.5 m
Diameter (m) 4.2 m

CZ-8A

An upgraded version of the Long March 8, the Long March 8A, has successfully debuted on February 11, 2025 with increased capability of up to 7 tonnes to a 700 km altitude sun-synchronous orbit.

  • Its hydrolox 2nd stage has a larger diameter (to match the 3.35 meters diameter core stage), and has 2 upgraded versions of the YF-75D engines (known as the YF-75H) with increased thrust to 10 tonnes each through measures such as increased turbopump speeds.
  • The Long March 8A can also use a larger 5.2 meters diameter payload fairing.
    CZ-8

    CZ-8

    CZ-8A

    CZ-8A


    Launch List:


    Type Nr Launch Vehicle Serial Nr Launch Date L.Time L. Site ID Year Payload Comment
    1 CZ-8Y122/12/2020 04:37:37 We, LC-2 2020-102 XJY 7
    2 CZ-8Y227/02/2022 03:06 We, LC-2 2022-019 Jilin-1 Mofang-02A (Xiamen Keji 1)
    3 CZ-8Y320/03/2024 00:31:28 We, LC-2 2024-051 Queqiao 2
    1 CZ-8AY1 / SatNet11/02/2025 09:30 We, LC-2 2025-030 HWD L02-01/09
    4 CZ-8Y6/G6011/03/2025 16:20 We, LC-1 2025-046 Qianfan Jigui G05-1/18
    2 CZ-8AY330/07/2025 07:49 Wenchang, LC-1 2025-162 Guowang-01/09
    3 CZ-8AY2/SatNet25/08/2025 20:00 We, LC-1 2025-187 Guowang-01/09
    4 CZ-8AY4/SatNet16/10/2025 01:33 We, LC-1 2025-231 Guowang-01/09
    5 CZ-8AY5/SatNet6/12/2025 08:00 We, LC-1 2025-285 Guowang-01/09
    6 CZ-8AY625/12/2025 23:25 We, LC-1 2025-311 Guowang-01/09 (HWD L17)

    Note: - All launches from Taiyuan (TSLC)
    - All "Launch Date" and "L. Time" are in UTC time.

    External links:


    Ref.: #98, #263 - update: 11.02.2026 Home
